- LCD, 3,600 lumens, WXGA
- Lamp replacement cycle of up to 20,000 hours in Eco mode
- Wireless projection capability (optional)
- Quiet operation for distraction-free projection
- 16,000:1 contrast ratio
PROJECTOR TYPE
LCD projector
LCD PANEL
PANEL SIZE
15.0 mm (0.59 in) diagonal (16:10 aspect ratio)
DISPLAY METHOD
Transparent LCD panel (x 3, R/G/B)
DRIVE METHOD
Active matrix method
NUMBER OF PIXELS
1,024,000 (1280 x 800 pixels) x 3
LIGHT SOURCE
230 W x 1 lamp
LIGHT OUTPUT*1
3,600 lm
LAMP REPLACEMENT CYCLE*2
Normal: 10,000 h/Eco: 20,000 h/Quiet: 10,000 h
FILTER REPLACEMENT CYCLE
Normal: 5,000 h/Eco: 6,000 h/Quiet: 10,000 h
RESOLUTION
1280 x 800 pixels
CONTRAST RATIO*1
20,000:1 (All white/all black, Iris: On, Image mode: Dynamic, Lamp control: Normal)
SCREEN SIZE [DIAGONAL]
0.76–7.62 m (30–300 in), 16:10 aspect ratio
CENTER-TO-CORNER ZONE RATIO*1
85 %
LENS
Manual zoom (1.2x), manual focus lens, F = 1.6–1.76, f = 19.16–23.02 mm, throw ratio: 1.48–1.78:1
KEYSTONE CORRECTION RANGE
Vertical: ±35 ° (Auto, Manual), Horizontal: ±35 ° (Manual) (TBD)
INSTALLATION
Ceiling/floor, front/rear
TERMINALS
HDMI® IN
HDMI 19-pin x 2 (Compatible with HDCP 1.4, Deep Color), Audio signal: Linear PCM (Sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
COMPUTER 1 IN
D-sub HD 15-pin (female) x 1 [RGB/S-Video/YPB(CB)PR(CR)]
COMPUTER 2 IN/1 OUT
D-sub HD 15-pin (female) x 1 [RGB]
VIDEO IN
Pin jack x 1
AUDIO IN 1
M3 (L,R) x 1
AUDIO IN 2
Pin jack x 2 (L,R)
AUDIO OUT
M3 (L,R) x 1 (Variable)
LAN
RJ-45 x 1 for network connection, 10Base-T/100Base-TX, PJLink™ (Class 1) compatible
SERIAL IN
D-sub 9-pin (female) x 1 for external control (RS-232C compatible)
USB A
USB Type-A (for Memory Viewer Light/Wireless Module [Output 5 V/2 A])
USB B
POWER SUPPLY
AC 100–240 V, 50/60 Hz
POWER CONSUMPTION
300 W
BUILT-IN SPEAKER
10 W monaural
CABINET MATERIALS
Molded plastic
OPERATION NOISE*1
Normal: 38 dB, Eco: 35 dB, Quiet: 30 dB
DIMENSIONS (W X H X D)
335 x 96*3 x 252 mm (13 3/16˝ x 3 25/32˝ *3 x 9 29/32˝ )
WEIGHT*4
Approx. 2.9 kg (6.4 lbs)
